This is our customized Prefab House for New Zealand customers. To increase the lighting in the room, we use transparent glass as the wall. At the same time, the doors and windows are also made of transparent glass, making the entire Prefab House look more upscale.
Product parameters | ||
---|---|---|
Bottom | Frame structure | 2.5mm thick profiled steel |
Floor | MGO board, waterproof, fireproof (Option Fiber cement) | |
Floor finishes | 1.8mm PVC flooring (extra cost) | |
Roof | Frame structure | 2.3mm thick profiled steel |
Outside cover | 0.426mm steel sheet | |
Insulation | glass wool | |
Ceiling | 0.25mm steel sheet bottom tile | |
Corner post | 4.5 cold rolled steel profile, galvanization, welded (160mm*160mm) | |
Wall panel | Sandwich panel with 50mm rock wool /tempered explosion-proof glass | |
Window | Aluminum alloy windows with dimensions 925mm*1200mm (3mm single glass) | |
Door | Steel door with dimensions 925mm*2035mm | |
Electricity | Light, Switch, Socket, distribution box, breaker, and wire | |
Painting | Automatic galvanizing and baking paint spray molding | |
Exterior size | 5950(L)*3000(W)*2800(H) |
We can customize more sizes than you need. | |||||||
---|---|---|---|---|---|---|---|
Model | External Dimensions | Internal Dimensions | Weight | ||||
Length | Width | Height | Length | Width | Height | ||
A | 3000mm | 1200mm | 2800mm | 2800mm | 1000mmm | 2520mm | 550KG |
B | 3000mm | 1200mm | 2800mm | 2800mm | 1800mm | 2520mm | 700KG |
C | 3000mm | 3000mm | 2800mm | 2800mm | 2800mm | 2520mm | 850KG |
D | 4000mm | 3000mm | 2800mm | 4800mm | 2800mm | 2520mm | 1000KG |
E | 5950mm | 1800mm | 2800mm | 5750mm | 1600mm | 2520mm | 1150KG |
F(20FT) | 5950mm | 3000mm | 2800mm | 5750mm | 2800mm | 2520mm | 1300KG |
G | 9000mm | 3000mm | 2800mm | 8800mm | 2800mm | 2520mm | 1450KG |
